Internal Permanent Magnet (IPM) with Rotor Skewing (Workshop)

This course provides a step-by-step guide to mapping forces from Ansys Maxwell® advanced electromagnetic field solver to Ansys Mechanical™ structural finite element analysis software for an Interior Permanent Magnet (IPM) motor with a skewed rotor. It covers project setup, including HPC configuration, project screening, data import, force calculation, postprocessing, and mechanical integration, ensuring efficient simulation and accurate force mapping for optimized motor design.

Learning Outcomes:

Following completion of this tutorial, you will be able to:

• Understand IPM motors forces with rotor skewing.
• Map forces from Ansys Maxwell software to Ansys Mechanical software.
• Start Ansys Maxwell software and create a project.
• Update HPC configuration for skewing.
• Validate Ansys Maxwell software project requirements.
• Initialize project with RPM and phase current settings.
• Import and validate phase current datasets.
• Set up mesh requirements and validate.
• Perform force calculations.
• Visualize forces at tooth locations.
• Reorder slices and map forces.
• Match stator dimensions in Ansys Mechanical software project.
• Map forces to Structural Harmonic analysis.
• Apply concepts to optimize motor design.

Prerequisites:

• Mapping Forces of an Internal Permanent Magnet (IPM) Motor with One Speed

Please note: These training materials were developed and tested in the 2025R1 release.
