This course is designed for CFD users who would like to post-process the results of a multiphase free surface simulation using the capabilities of Ansys EnSight™ simulation data visualization software. The example case is a simulation of tank sloshing.
This course proceeds through free surface post-processing in a step-by-step process. You begin by learning how to visualize both the free surface and the wetted portion of wall surfaces, and then how to use the flipbook capability to speed up the animation of transient data. Following this you will learn how to get numerical and averaged values, such as the average velocity below the free surface, and to finish, you will learn to visualize the center of gravity of the fluid and how to create a Python script to automate this visualization.
Learning Outcomes:
Following completion of this course, you will be able to:
- Visualize the free surface and wetted wall surfaces using Ansys EnSight.
- Speed up the animation of transient data using the flipbook capability.
- Calculate numerical outputs including, among others, the wetted surface fraction and the free surface height.
- Calculate averaged values, such as the average velocity below the free surface.
- Visualize the center of gravity location of the fluid.
- Create and apply a Python script to automate the visualization of the center of gravity.
Prerequisites:
You must take the courses: ‘Introduction to Ansys Ensight’ and ‘EnSight Python Scripting’ before taking this course.
Please note: These training materials were developed and tested in the 2021R2 release.
-
Cost: $450.00
- Course Duration: 2-4 HOURS
- Skill Level: Expert
- Skills Gained: Surface Visualization, Transient Animation, Data Analysis, Python Automation
