This workshop introduces you to the process of simulating a coaxial bend using Ansys HFSS™ high-frequency electromagnetic simulation software. It covers essential steps such as setting up wave ports, defining analysis parameters, validating the design, and interpreting S-parameters and field plots. You will also learn how to apply finite conductivity boundaries and how to compare the results between the two cases using the same design.
Learning Outcomes:
Following completion of this workshop, you will be able to:
- Set up a coaxial bend model in HFSS and assign appropriate wave ports.
- Configure analysis setup and frequency sweep.
- Validate to ensure proper simulation setup and analyze design.
- Interpret S-parameters for reflection and transmission characteristics.
- Apply finite conductivity boundary and re analyze the design.
- Compare results between ideal and realistic conditions (PEC vs finite conductivity).
- Visualize electromagnetic fields and create animations for better understanding.
Prerequisites:
- Getting Started with HFSS Software course.
-
Cost: $450.00
- Course Duration: 1-2 HOURS
- Skill Level: Beginner
- Skills Gained: Coaxial Bend Modeling and Analysis, S-Parameter Analysis, Frequency Sweep and Wave Port Configuration, Electromagnetic Field Visualization and Conductivity Analysis
