This course is part of Ansys HFSS EMI EMC CISPR25 learning plan using Ansys Electronics Desktop (AEDT)™ electronics systems design platform. In this course, the radiated emission (RE) simulation of a PCB is performed using Ansys HFSS™ high-frequency electromagnetic simulation software and AEDT Circuit as per CISPR25 standard.
Learning Outcomes:
Following completion of this course, you will be able to:
- Setup radiated emission simulation using PCB, cables and antenna inside a chamber in Ansys HFSS software.
- Set up Ansys HFSS EM blocks in AEDT Circuit schematics and drive with transient signals.
- Import CISPR 2008 standard templates to overlay on plots.
Prerequisites:
- Ansys HFSS Getting Started.
- Set up and edit the schematic symbols for the HFSS EM block in AEDT Circuit.
- Schematic component placement, connection and transient signal source setup in AEDT Circuit.
- Ansys HFSS EMI EMC CISPR25 - CE Local Ground.
- Ansys HFSS EMI EMC CISPR25 - CE Remote Ground.
- Familiarity with emissions testing and the CISPR25 2008 specification.
Please note: These training materials were developed and tested in 2021 R2 release. However, due to kernel change, simulation files compatible from 2025R1 version are also provided.
-
Cost: $450.00
- Course Duration: 2-4 HOURS
- Skill Level: Expert
- Skills Gained: Setup radiated emission simulation using PCB, cables and antenna inside a chamber in Ansys HFSS software, Set up Ansys HFSS EM blocks in AEDT Circuit schematics and drive with transient signals, Import CISPR 2008 standard templates to overlay on plots
