Ansys Electronics Desktop for Filter Design

$450.00

4-6 HOURS

Ansys

Login to Check Availability
SKU: PL-EL-00024 Categories: , Tag:

COMPLETION
BADGE

Course Completion Badge

Login to Check Availability

This course is a detailed workflow with recommendations for using Ansys Electronics Desktop (AEDT)™ electronics systems design platform, Ansys Nuhertz® FilterSolutions™ radio frequency filter synthesis software and Ansys SynMatrix Filter™ radio frequency filter synthesis and optimization software to design RF and microwave filters. The course includes sections dedicated to cavity and waveguide filters, lumped element filters and planar filter designs.

Learning Outcomes:

Following completion of this course, you will be able to:

  • Synthesize filter responses using the Ansys NuHertz tool.
  • Understand the coupling matrix and how to use it for cavity filter design.
  • Create accurate Ansys HFSS simulations of planar and cavity filters.
  • Understand and implement the port tuning method for filter co-design.

Prerequisites:

  • A Nuhertz license is required to complete Workshop on Nuhertz Planar Filter Design and Export to AEDT.
  • A Nuhertz and Modelithics License is required to complete Workshop on NuHertz Export to AEDT Using Modelithics.
  • All other workshops only require an AEDT License. SynMatrix is recommended for Workshop on Cavity Filter Synthesis, but not essential.
  • Ansys HFSS Getting Started course

Please note: These training materials were developed and tested in the 2023 R2 release.

  • Cost:
    $450.00
  • Course Duration: 4-6 HOURS
  • Skill Level: Expert
  • Skills Gained: Synthesize filter responses, Understanding and using the coupling matrix for cavity filter design, Using AEDT Platform, Using Ansys SynMatrix Filter synthesis, Using Ansys Nuhertz filter solutions

No reviews available for this learning resource.
