This tutorial is dedicated to the analytical model validation through experimental procedures or FEA calculations for the 3-phase induction motors using Ansys Motor-CAD® dedicated electric motor design tool for multiphysics simulation .
The example test model corresponds to a 63/71 frame, 24 slots, 4 poles, Aluminium die-cast rotor, variable speed drive induction motor.
Learning Outcomes:
Following completion of this workshop, you will be able to:
- Extract induction motor equivalent circuit parameters from experimental tests.
- Estimate magnetic characteristics and core losses.
- Correlate analytical models with FEA simulations.
- Determine rotor parameters using locked-rotor testing.
- Validate machine performance under load conditions.
- Calibrate induction motor models for high-fidelity simulation.
Prerequisites:
- Getting Started with Ansys Motor-CAD Software course.
