      DoodlerD
      Subscriber

      Hi!

      How can I create a fillet using the pull tool for a structure that was created as a step file with surfaces? It does not seem to work for shell structures?

    • October 18, 2021 at 4:47 pm
      DoodlerD
      Subscriber
      I figured it out. The step file should have surfaces of the entire cross section created through a loft and not a patch. Alternatively, surfaces need to merged to get the pull tool to work.
      Thank you.
Viewing 1 reply thread
  • The topic ‘Spaceclaim Pull Tool’ is closed to new replies.
